Lexmark E460DN - Cover Open Sensor

4-8
4513-630, -63W, -6EW
Cover open sensor
1. Remove the right side cover. See “Right side cover assembly removal” on page 3-62.
2. Disconnect the cable (A) from the controller board.
3. Use a #1 Phillips screwdriver to remove the screw (B) holding the sensor.
4. Remove the cover open sensor.
AB
