Diagnostics information 2-25

4513-630, -63W, -6EW

Dead machine service check

CAUTION: Check the AC line voltage. The voltage should be within the following limits:

• 100 V ac (volts alternating current) – 127 V ac for the 110 V printer

• 200 V ac – 240 V ac for the 220 V printer

FRU Action

LVPS/HVPS

Unplug the printer. Remove the LVPS/HVPS, and check the fuses for continuity.

• If open, then replace the LVPS/HVPS.

• If not open, then check the switch continuity across its conductors with the switch on.

Turn the switch off. Plug the AC line into the LVPS/HVPS and switch unit on.

Note: Voltages may be exposed at several places on the board. Do these verifications, and

then unplug the card:

• If voltages are not correct, then replace the LVPS/HVPS.

• If voltages are correct, then check the controller board. See “Controller board service

check” on page 2-23.

Pins Voltage

CN201-6, 17,

+24 V dc

CN201-10, 12,

14, 16, 18

Ground

CN201-1,3, 5,

11,13, 15

+5 V dc

Other manuals for Lexmark E460DN

Questions and Answers:

Need help?

Do you have a question about the Lexmark E460DN and is the answer not in the manual?

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB
