Lexmark E460DN Service Manual

2-6 Service Manual
4513-630, -63W, -6EW
Load <src> with <Custom Type Name> • Load the input source with the correct type and size media.
• Cancel the current job.
Load <src> with <Custom String>
Load <src> <size>
Load <src> <type> <size>
Maintenance Replace the maintenance items and, if necessary, reset the printer
maintenance counter.
Menus Disabled The printer menus are disabled. The printer settings cannot be changed
from the control panel.
Note: A job can still be canceled.
Contact a system support person.
Network A network interface is the active communication link.
Network Card Busy An internal print server (also called an internal network adapter or INA) is
being reset. Wait for the message to clear.
Not Ready The printer is not ready to receive or process data. Someone pressed
to take the printer offline. Press to make the printer ready to receive
jobs.
Parallel A parallel interface is the active communication link.
Performing Self Test The printer is running the series of start-up tests it performs after it is
turned on. Wait for the message to clear.
Power Saver • Send a job to print.
• Press to warm the printer to normal operating temperature and
display the Ready message.
Printing Directory List The printer is processing or printing a directory of all files stored in flash
memory. Wait for the message to clear.
Printing Font List The printer is processing or printing a list of all available fonts for the
specified printer language. Wait for the message to clear.
Printing Menu Settings The printer is processing or printing the menu settings page. Wait for the
message to clear.
Printing Device Statistics The printer is printing statistical information about the printer. Wait for the
message to clear.
Printing Quality Test Pages The printer is formatting and printing the Print Quality Test, which consists
of 4 pages. Page 1 contains a mixture of graphics and text, pages 2 and 3
contain only graphics, and page 4 is a blank page. If Duplex is turned on,
then the pages are duplexed; otherwise they are simplexed. Wait for the
message to clear.
Prog Engine Code
DO NOT POWER OFF
The printer is programming new engine code. Wait for the message to
clear and the printer to reset.
Warning: Do not turn the printer off while this message is displayed.
Program Flash
DO NOT POWER OFF
The printer is storing resources, such as fonts or macros, in flash memory.
Wait for the message to clear.
Warning: Do not turn the printer off while this message is displayed.
User attendance messages (Continued)
Message Action

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
