Understanding the MFP control panel
10
Learning about the MFP
5 Dial Pause Press to cause a two- or three-second dial pause in a fax
number. The button only functions within the Fax menu or
with fax functions.
Press from the home screen to redial a fax number.
When outside of the Fax menu, fax function, or home
screen, pressing Dial Pause causes an error beep.
When sending a fax, in the Fax To: field, a Dial Pause
press is represented by a comma (,).
6 Clear All When in the function menus, such as Copy, Fax, E-mail,
and FTP, it returns all settings to their default values, and
then returns the MFP to the main function screen.
7 Start Press to initiate the current job indicated on the control
panel.
From the home screen, press it to start a copy job with
the default settings.
If pressed while a job runs through the scanner, the
button has no effect.
8 Stop Press to cause the printing or scanning to stop.
During a scan job, the scanner finishes scanning the
current page and then stops, which means paper may
remain in the automatic document feeder (ADF).
During a print job, the print media path is cleared before
the printing stops.
Stopping appears on the control panel during this
process.
9 Backspace Within the Copy menu, which is accessed by touching
the Copy button, press Backspace to delete the right-
most digit of the value in the Copy Count. The default
value of 1 appears if the entire number is deleted by
pressing Backspace numerous times.
Within the Fax Destination List, press Backspace to
delete the right-most digit of a number entered manually.
It also deletes an entire shortcut entry. Once an entire
line is deleted, another press of Backspace causes the
cursor to move up one line.
Within the E-mail Destination List, press Backspace to
delete the character to the left of the cursor. If the entry is
in a shortcut, the entire entry is deleted.
10 Asterisk (*) * is used as part of a fax number or as an alphanumeric
character.
Callout Control panel item Function
