Replacing the shield
77
Installing and removing options
Replacing the shield
After you have installed options on the printer system board, follow these steps to reattach the shield and close the doors.
1 Align the slots at the top of the access cover with the screws near the top of the printer.
2 Slide the cover up under the top cover lip as far as it will go.
3 Insert and tighten the screws at the top of the cover.
4 Insert and tighten the screws at the bottom of the cover.
