Parts catalog 7-19

4061-xx0

Assembly 9: Integrated 250-sheet paper tray

Asm-

Index

Part

number

Units/

mach

Units/ kit

or pkg

Description

9—1 40X0087 1 1 Integrated 250-sheet tray

2 40X0092 1 1 Side restraint—250-sheet tray

3 40X0093 4 1 Wear strips

4 40X0263 1 1 Pass thru plate—250-sheet tray

5 40X0094 1 1 Wear plate—250-sheet tray

6 40X0105 2 1 Restraint pad

7 40X0090 1 1 Back restraint—250-sheet tray
