Lexmark T640 - Page 392

To Next Page

To Previous Page

A-6 Service Manual

4061-xx0

5. Slide the shield to the right, and then remove it.

6. Set the shield aside.

Use the illustration to locate the connector for the card you want to install.

Firmware card connector

Memory card connector

Option card connectors
