92Operations - TN3270E SETUP: NETWORK SETUP > Connect Status
Connect Status This Network Setup option displays the connection status with the
host. The option cannot be changed by the user.
Normally only the primary status is shown. If problems occur, a last
response message is appended to the primary status message. The
complete status message text may not be displayed. Refer to the
tables below.
Connect Status: Primary status messages Comments
Connected to server. LU name: [LU NAME] A Telnet connection is established and the SCS/TNe Emulation is
ready to receive print jobs. The LU name displayed is the name
negotiated with the Telnet server. Refer to the LU Name and Device
Type options.
Negotiating with TN server The SCS/TNe Emulation has succesfully established a TCP/IP
connection and is negotiating the Telnet device configuration.
Not Configured The IP Address, Hostname, or LU Name in the TN3270E SERVER
INFO menu has not been configured.
Print Inactive * One of the following conditions exists and is preventing a session
from being estalished.
1 Print Active = No. Solution: Set to Yes. (Path: Menus > Option Card Menu >
SCS/TNe MENU > TN3270E SETUP > NETWORK SETUP).
2 NPA Mode = Off. Solution: Set to Auto. (Path: Menus > Network/Ports > print
server to be used for SCS printing > NPA Mode).
3 Cable is not plugged into print server. Plug in cable.
4 Network is down. Check network.
