3 Technical data
3.1 Operating and storage conditions
Table 3 Operating and storage conditions
Range Data
Ambient operating temperature range 5 °C to 40 °C
Ambient operating humidity range 80% up to 31 °C
Reducing linearly to 50% at
40 °C
Maximum operating altitude 3000 m
Ambient storage temperature range -30 °C to 70 °C
Maximum humidity (storage in original
packaging)
≤ 95 % RH
Equipment type Indoor use
Enclosure protection IP20
Table 4
Environmental conditions
Pollution Pollution degree 2
Installation Installation category II
Altitude restriction Maximum 3000 m
Area of use Indoor
3.2 Mechanical data
Table 5 Mechanical data
Range
25 35
Mass 28 kg 28.10
Inlet connection DN 25 ISO-KF
Overall dimensions (L x W x H) 494 x 248 x 304 mm
Maximum tilt angle for operation ± 5°
Maximum tilt angle for transport 30°
Nominal rotational speed 15000 rpm
Outlet connection DN 25 ISO-KF
300902516_002 - 10/2020 - © Leybold
14
Technical data
