Description
8
GA 05.130/3.02 - 05/98
1.5 Standard specification
MAG
The turbomolecular pumps are shipped complete,
sealed in a PE bag containing a desiccant.
The maximum effective life of the desiccant is one year.
The intake flange is sealed with a transport seal, the
forevacuum flange with a plastic cap.
For the intake flange, a centering ring with FPM O-ring,
outer ring, and a splinter guard are enclosed.
We also provide the bolts for attaching the pump to your
tool.To avoid any safety risk we highly recommend using
only the bolts provided with the pump. Refer also to Sec-
tion 2.4 „Connecting the MAG ...“.
The electronic frequency converter MAG DRIVE as well
as the cables required for operation must be ordered
seperately.
In addition, a seal kit is included to seal the pump tightly
if it is removed from the process.
MAG.DRIVE
• Converter
• Line supply cable with USA connector, approx. 3m
• Line supply cable with EURO connector, approx. 3 m
• Spare fuses (miniature fuses 5 x 20 mm)
F1 for the mains power supply (F8A) (only
MAG.DRIVE L2)
F2 for the power supply of the active magnetic bea-
ring (T3.15A) (only MAG.DRIVE L2)
F3 for the heating (F4A)
Cable Set
• Bearing cable
• TMS cable
• Drive cable
