Purge Gas
Purge gas connection pressure, abs. 1.2 - 2.0 bar
Purge gas: dry nitrogen, argon or similar
Purge gas throughput
at purge gas pressure 1.5 bar abs. 0.6 mbar·l·s
-1
36 sccm
Connection: VCR Nut 1/4“
MAG.DRIVE
Voltage range 200 - 240 V +10% -15%
Line supply frequency 50 / 60 Hz
Load
Stand-by approx. 100 W
Continuous (rated speed) 810 W
Maximum 1800 W
Max. voltage motor 60 V
Maximum pump current (Accel.) 20 A dc_peak
Continuous pump current, max. 13 A dc_peak
Maximum frequency 480 Hz
Load capability, relay output 42 V, 1 A
Temperature during operation
MAG.DRIVE L 0-40° C
MAG.DRIVE L2 0-45° C
Storage temperature - 10° C to + 60° C
Relative air humidity Class F acc. to DIN 400 40
Weight 16 kg
Dimensions W x H x D (mm) 465 x 222 x 350
+ connector depth 130
The units have degree of protection IP20 in accordance
with EN 60529
(protection against the ingress of solid foreign bodies >
12 mm diameter (finger). It is not protected against the
ingress of water with damaging effects.)
An increased degree of protection, e.g. IP54 can only be
implemented by mounting the converter in an additional
housing.
1.7 Ordering data
Order No.
MAG 1600 C 894 14
MAG W 1600 C 894 15
MAG 2000 C 894 16
MAG W 2000 C 894 17
MAG 1600 CT 894 28
MAG W 1600 CT 894 29
MAG 2000 CT 894 30
MAG W 2000 CT 894 31
Seal Kit DN 200 200 91 684
Seal Kit DN 250 200 91 641
MAG.DRIVE L converter 857 24
MAG.DRIVE L2 converter 857 23
Connecting cables, converter / pump
Length Cable Cable Cable
BEARING DRIVE TMS
————————————————————————
3 m 859 50 859 51 859 52
5 m* 859 53 859 54 859 55
10 m* 859 56 859 57 859 58
20 m* 859 62 859 63 859 64
3 m with
bended plugs 859 68 859 69 859 70
The cables with straight plugs are shown in Fig. 3, the
cables with bended plugs in Fig. 34.
• MAG.WIN, an operator control interface
which can run under Windows with user
instructions as Windows help on request
• Connecting cable serial interface (front panel,
9-pin D-connector), approx. 5 m long on request
* only permissible if the pump is mounted in a vertical position
Description
10
GA 05.130/3.02 - 05/98
