LG 47WV30MS - RS-232 Control Commands Overview

68
ENG
ENGLISH
RS-232 CONTROL
01. Power (Command: k a)
- To control power On/Off the display.
Transmission
[k][a][ ][Set ID][ ][Data][Cr]
Data
00: Power Off
01: Power On
Acknowledgement
[a][ ][Set ID][ ][OK/NG][Data][x]
* Note: In this mode, display will send the
acknowledgement after power on processing
completion. There might be a time delay between
command and acknowledgement.
04. Energy Saving (Command: j q)
- To control the energy saving function.
Transmission
[j][q][ ][Set ID][ ][Data][Cr]
Data
00: Off
01: Minimum
02: Medium
03. Maximum
05. Screen Off
Acknowledgement
[q][ ][Set ID][ ][OK/NG][Data][x]
05. Picture Mode (Comman : d x)
- To select the picture mode.
Transmission
[d][x][ ][Set ID][ ][Data][Cr]
Data
00: Vivid
01: Standard
02. Cinema
03. Sport
04: Game
Acknowledgement
[j][ ][Set ID][ ][OK/NG][Data][x]
02. Input Select (Command: x b)
- To select input source for display.
Transmission
[x][b][ ][Set ID][ ][Data][Cr]
Data
20: AV
40: Component
60: RGB PC
70: DVI-D(PC)
80: DVI-D(DTV)
90: HDMI(DTV)
A0: HDMI(PC)
Acknowledgement
[b][ ][Set ID][ ][OK/NG][Data][x]
* Use this feature depending on your model
Supports
Model
Data
47WV30BS
47WV30-BAAM
47WV30-BAAL
47WV30BR
47WV30MS
20H x o
40H o o
60H o o
70H o o
80H o o
90H o o
A0H o o
03. Aspect Ratio (Command: k c)
- To adjust the screen format.
Transmission
[k][c][ ][Set ID][ ][Data][Cr]
Data
01: 4:3
02: 16:9
04: Zoom
09: Just Scan(720p or higher)/ 1:1
10~1F: Cinema Zoom 1~16
Acknowledgement
[c][ ][Set ID][ ][OK/NG][Data][x]
