LG 47WV30MS - RS-232 Tile and Fan Control Commands

76
ENG
ENGLISH
RS-232 CONTROL
41. Tile H Position (Command: d e)
- To set the Horizontal position
* Only available when Tile Mode On.
Transmission
[d][e][ ][Set ID][ ][Data][Cr]
Data
00~64: -50 ~ 50
Acknowledgement
[e][ ][Set ID][ ][OK/NG][Data][x]
42. Tile V Position (Command: d f)
- To set the Vertical Position.
* Only available when Tile Mode On.
Transmission
[d][f][ ][Set ID][ ][Data][Cr]
Data
23~41: -15 ~ 15 (for RGB)
Acknowledgement
[f][ ][Set ID][ ][OK/NG][Data][x]
46. FAN Fault Check (Command: d w)
- To set Fan control on/off.
Transmission
[d][w][ ][Set ID][ ][Data][Cr]
Data
FF: Data should be always ff in hexadecimal.
Acknowledgement
[w][ ][Set ID][ ][OK/NG][Data][x]
43. Tile H Size (Command: d g)
- To set the Horizontal size.
* Only available when Tile Mode On.
Transmission
[d][g][ ][Set ID][ ][Data][Cr]
Data
00~64: -50 ~ 50
Acknowledgement
[g][ ][Set ID][ ][OK/NG][Data][x]
44. Natural Mode (in Tile Mode) (Comman : d j)
- To assign the Tile Natural mode for Tiling function.
Transmission
[d][j][ ][Set ID][ ][Data][Cr]
Data
00: Off
01: On
Acknowledgement
[j][ ][Set ID][ ][OK/NG][Data][x]
45. FAN Control (Command: d o)
- To set Fan control on/off.
Transmission
[d][o][ ][Set ID][ ][Data][Cr]
Data
00: Auto
01: On
02: Manual
Acknowledgement
[o][ ][Set ID][ ][OK/NG][Data][x]
