Installing speakers
The unit allows you to use 2.2 channel system.
The following illustration shows an example
of positioning the system. Note that the
illustrations in these instructions di er from the
actual unit for explanation purposes.
Example of 2.2 channel speaker system
con guration
F
C
B
A
D
E
A
Front speaker (left)/
B
Front speaker
(right)
Place the front speakers to the sides of the
monitor or screen and as ush with the screen
surface as possible.
C
/
D
Subwoofer
The position of the subwoofer is not so
critical, because low bass sounds are not
highly directional. But it is better to place
the subwoofer near the front speakers. Turn
it slightly toward the center of the room to
reduce the wall re ections.
E
Unit
CAUTION
• Be careful that the speaker
should not fall down.
Otherwise it may result in the
speaker malfunctioning and
causing personal injury and/
or property damage.
• Make sure to install the speaker with other
people in order to prevent it from falling and
causing injuries to the installer.
