LG HECTO User Manual

37
Setting Up the TV
Using the Edge Adj Function
To prevent the screen image from
becoming trapezoidal, Edge Adj adjusts
the top and bottom width of the image
if the Laser TV is not set up at a right
angle to the screen.
Because the Edge Adj function may
cause inferior screen image quality, use
this function only when it is not possible
to set up the Laser TV at an optimal
angle.
1 Adjust the screen using the EDGE
ADJ button.
• The value range of Edge Adj is as
follows.
Left top (H: 0 ~ 100, V: 0 ~ 100)
Right top (H: -100 ~ 0, V: 0 ~ 100)
Left bottom (H: 0 ~ 100, V: -100 ~ 0)
Right bottom (H: -100 ~ 0, V:-100 ~ 0)
2 Press the OK button after
adjustment.
• While you use the Test Pattern
option, the keys on the control
panel do not work.
NOTE
Using the Input List
Using the Input List
1 Press the INPUT button to display
the input selection screen.
2 Select an input signal using the
INPUT button to switch the Laser
TV to the desired input mode. You
can use the or button to switch
between all the input modes.
Selecting an Input Label
You can select an input label to display
which devices are connected to which
input ports.
1 Press the INPUT button to display
the input selection screen.
2 Press the red button.
3 Press the or button to select an
input and press OK button.
4 Use the , , or button to
select a device name.
