4
ENGLISH
ASSEMBLING AND PREPARING
y
You can set the Power indicator to on or off by selecting
OPTION
in the main menus.
y
Local keys work on
Power, Channel, Volume
and
Input
only.
NOTE
Parts and buttons
button Description
MODE " "
Selects the mode.(Channel
Volume
Input)
Channel Scrolls through the saved Channel.
Volume Adjust the Volume level.
Input Changes the Input source.
,
Adjusts the mode button level.
HDMI IN
AV IN
VIDEO
ANTENNA /
CABEL IN
(MONO)
L
USB IN
RGB IN (PC)
AUDIO
R
Remote Control
Sensor
Buttons
Connection panel ( See p.33)
y
(Power Button)
y
Power Indicator
»
Lighting On: Turned on
»
Lighting Off: Turned off

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG M2241A and is the answer not in the manual?

LG M2241A Specifications

General IconGeneral
3DNo
Panel typeTN+Film
Pixel pitch0.248 x 0.248 mm
Aspect ratio16:9
Display diagonal22 \
Display technologyLED
Supported video modes1080p
Viewing angle, vertical170 °
Contrast ratio (dynamic)50000:1
Display number of colors16.78 million colors
Viewing angle, horizontal160 °
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
Built-in speaker(s)-
HDCPYes
USB hub version2.0
DVI-D ports quantity0
Cables includedVGA
Panel mounting interface- mm
Power consumption (off)0.5 W
Power consumption (standby)1 W
Power consumption (typical)30 W
Package depth140 mm
Package width594 mm
Package height472 mm
Package weight5400 g
Product colorBlack
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)166.39 mm
Weight (with stand)3600 g
Depth (without stand)61 mm
Width (without stand)520.8 mm
Height (without stand)422.6 mm
Weight (without stand)3400 g
