2. Specifications
5
MULTI Standard
Indoor Unit
Model Name AMNQ18GSKAA AMNQ24GSKAA
Power Supply V, Ø, Hz
220-240, 1, 50 220-240, 1, 50
220, 1, 60 220, 1, 60
Capacity Cooling kW 5.0 7.1
Power Input Min./Nom./Max. W x No. 15 / 21 / 40 26 / 39 / 60
Running Current Min./Nom./Max. A 0.14 / 0.20 / 0.25 0.22 / 0.28 / 0.40
Casing Color - Munsell 7.5BG 10/2 (RAL 9016)
Dimensions
Body
W x H x D mm 998 x 345 x 210 998 x 345 x 210
W x H x D inch 39-9/32 x 13-19/32 x 8-9/32 39-9/32 x 13-19/32 x 8-9/32
Shipping
W x H x D mm 1,080 x 422 x 281 1,080 x 422 x 281
W x H x D inch 42-17/32 x 16-5/8 x 11-1/16 42-17/32 x 16-5/8 x 11-1/16
Weight
Body kg (lbs) 11.2 (24.7) 11.8 (26.0)
Shipping kg (lbs) 13.0 (28.7) 13.6 (30.0)
Heat Exchanger
(Row x Column x Fins per inch)
x No.
- (2 x 16 x 20) x 1 (2 x 16 x 20) x 1
Face Area
m
2
(ft
2
)
0.25 (2.69) 0.25 (2.69)
Fan
Type - Cross Flow Fan Cross Flow Fan
Air Flow Rate
H / M / L
m
3
/min
14.2 / 11.3 / 9.9 15.2 / 12.7 / 10.2
H / M / L
ft
3
/min
501 / 399 / 350 537 / 448 / 360
Fan Motor
Type - BLDC BLDC
Output W x No. 30 x 1 60 x 1
Sound Pressure Level H / M / L dB(A) 44 / 38 / 35 46 / 41 / 36
Piping
Connections
Liquid mm(inch) Ø 6.35 (1/4) Ø 6.35 (1/4)
Gas mm(inch) Ø 12.7(1/2) Ø 12.7(1/2)
Drain O.D. / I.D. mm Ø 21.5 / 16.0 Ø 21.5 / 16.0
Safety Devices
- Fuse Fuse
- Thermal Protector for Fan Motor Thermal Protector for Fan Motor
Connections Method - Flared Flared
Power and Communication Cable (included Earth)
No. x mm
2
(AWG)
4C x 0.75 (18) 4C x 0.75 (18)
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national code. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound Level Values are measured at Noise Measuring chamber accordance with standard. Therefore, these values depend on the ambient conditions
and values are normally higher in actual operation(Sound Pressure : LG Internal standard, Sound Power : EN 12102 (ISO 3741).
4. Capacities are net capacities and based on the following conditions. Refer to the Outdoor Unit Specifications for calculating the real capacity.
• Cooling : Indoor Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• Heating : Indoor Ambient Temp. 20°CDB / 15°CWB, Outdoor Ambient Temp. 7°CDB / 6°CWB
• Interconnected Pipe is standard length and difference of Elevation (Outdoor ~ Indoor Unit) is 0m.
