15
MULTI Standard
Outdoor Unit
6. Capacity Correction factor
■ Rate of change in capacity due to the branch piping length
9k Btu/h (2.5 kW) models
12k Btu/h (3.5 kW) models
18k Btu/h (5.0 kW) models
24k Btu/h (7.1 kW) models
Notice
Factor values for heating capacity are not corresponded to Cooling only model.
Piping length(m)
Rate of change in capacity
Cooling(%) Heating(%)
7.5 100.0 100.0
10 98.0 99.0
15 94.8 97.4
20 91.6 95.8
25 88.4 94.2
Piping length(m)
Rate of change in capacity
Cooling(%) Heating(%)
7.5 100.0 100.0
10 97.6 98.6
15 93.8 96.4
20 89.9 94.1
25 86.1 91.9
Piping length(m)
Rate of change in capacity
Cooling(%) Heating(%)
7.5 100.0 100.0
10 98.6 99.6
15 96.4 99.0
20 94.1 98.3
25 91.9 97.7
Piping length(m)
Rate of change in capacity
Cooling(%) Heating(%)
7.5 100.0 100.0
10 98.2 99.2
15 95.4 98.0
20 92.4 96.6
25 89.6 95.4
