2. Installation Space
4
MULTI/SINGLE CAC
Installation of Outdoor Units
2.1.1 Where there is an obstacle on the air intake side:
■ Stand alone installation
No obstacle above
[Unit : mm(inch)]
Obstacle above, too
[Unit : mm(inch)]
■ Collective installation
[Unit : mm(inch)]
• Obstacle on the air intake side only • Obstacle on the both left and right sides
• Obstacle on the air intake side, too • Obstacle on the air intake side, and both sides
• Obstacle on the both sides • Obstacle on the air intake side, and both sides
300(11-13/16)
or more
300(11-13/16)
600(23-19/32)
or more
or more
300(11-13/16)
1000(39-3/8) or more
or more
500(19-11/16) or less
300(11-13/16)
300(11-13/16)
1000(39-3/8) or more
600(23-19/32)
or more
500(19-11/16) or less
or more
or more
1000(39-3/8)
or more
600(23-19/32)
or more
600(23-19/32)
or more
300(11-13/16)
or more
1000(39-3/8)
or more
600(23-19/32)
or more
600(23-19/32)
or more
300(11-13/16)
or more
500(19-11/16) or less
1000(39-3/8) or more
