LG MULTI AMNQ09GSJAA - Piping Diagrams; Cross Flow Fan

8
MULTI Standard
Indoor Unit
4. Piping Diagrams
LOC. Description PCB Connector
Th1 Thermistor for suction air temperature
CN_TH1
Th2 Thermistor for evaporator inlet temperature
Th3 Thermistor for evaporator outlet temperature CN_TH2
Heat exchanger
Gas pipe connection port
(flare connection)
Liquid pipe connection port
(flare connection)
Cooling
M
Cross Flow Fan
Th3
Th2
Th1
