2. Specifications
4
MULTI Standard
Outdoor Unit
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Power factor could vary less than ±1% according to the operating conditions.
4. Sound pressure level is measured on the rated condition in the anechoic rooms by ISO 3745 standard.
Sound power level is measured on the rated condition in the reverberation rooms by ISO 3741 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
5. Performances are based on the following conditions :
• *Cooling : Indoor Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• *Heating : Indoor Ambient Temp. 20°CDB / 15°CWB, Outdoor Ambient Temp. 7°CDB / 6°CWB
• Interconnected Pipe is standard length and difference of Elevation (Outdoor ~ Indoor Unit) is 0m.
6. This product contains Fluorinated greenhouse gases.
Global Model Names A3UQ34GFAB
Cooling Capacity*
kW 10.0
Btu/h 34,000
Power Input Cooling* kW 3.32
Power Supply V , Ø , Hz
220-240, 1, 50
220, 1, 60
Running Current Cooling* A 14.7
Power Factor Rated - 0.97
Power Supply Cable (included Earth) No. × mm² 3C × 2.5
Exterior
Color - Warm Gray
RAL (Classic) - RAL 7044
Dimensions W × H × D mm 870 x 650 x 330
Net Weight kg (lbs) 46.8 (103.2)
Shipping Weight kg (lbs) 50.6 (111.6)
Compressor
Type - Twin Rotary
Model Model × No. GKT208MAB × 1
Motor type - BLDC
Motor Output W × No. 1,500 (at 60Hz) × 1
Refrigerant
Type - R410A
GWP (Global Warming Potential) - 2,087.5
Precharged Amount g (oz) 1,900 (67.0)
t-CO₂eq.
- 3.97
Control - Electronic Expansion Valve
Chargeless-Pipe Length m (ft) 37.5 (123.0)
Additional Charging Volume g/m (oz/ft) 20 (0.22)
Refrigerant Oil
Type - FVC68D
Charged volume cc × No. 670 × 1
Heat Exchanger (Row×Column×Fins per inch) × No. - (2 × 28 × 14) × 1
Fan
Type - Propeller
Air Flow Rate m³/min × No. 50 × 1
Fan Motor
Type - BLDC
Output W × No. 85.4 × 1
Sound Pressure Level Cooling Rated dB(A) 58
Piping Connections
Liquid Outer Dia. × No. mm(inch) Ø 6.35 (1/4) × 3
Gas Outer Dia. × No. mm(inch) Ø 9.52 (3/8) × 3
Piping Length
Total Piping Max. m (ft) 75 (246.1)
Main Piping
Standard m (ft) -
Max. m (ft) -
Total Branch Max. m (ft) -
Each Branch
Standard m (ft) 7.5 (24.6)
Max. m (ft) 25 (82.0)
Maximum Height
Difference
ODU~IDU Max. m (ft) 15 (49.2)
IDU~IDU Max. m (ft) 7.5 (24.6)
Operation Range
(Outdoor Temperature)
Cooling Min. ~ Max. ºC(ºF)DB -5 (23.0) ~ 48 (118.4)
