5. Capacity tables
12
MULTI Standard
Outdoor Unit
5.2 A3UQ24GFAB
Cooling Capacity
Note
1. DB : Dry bulb temperature(℃), WB : Wet bulb temperature(℃)
2. TC : Total capacity(kW)
3. PI : Power Input (kW, Compressor + indoor fan motor + outdoor fan motor)
4. All capacities are net. A deduction (cooling mode) or an addition (heating mode) of Capacity due to operating heat of indoor unit motor is reflected.
5. Capacities are based on the following conditions ;
- Interconnecting Piping Length (Both Main pipe and Branch pipe) is standard length.
- Difference of Elevation (Outdoor ~ Indoor Unit) is 0 m.
6. Direct interpolation is permissible. Do not extrapolate.
7. Rated capacities and power inputs are based on standard temperature and piping conditions, and it can be found on specifications table. Except for rated value, the
performance is not guaranteed.
8. In accordance with the test standard(or nations) and indoor unit’s combinations, the rating will vary slightly.
Combination capacity
index (kBtu/h)
Outdoor Air
Temp. (°CDB)
Indoor Air Temp. (°CWB)
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
1 Unit Operation
9
22 2.51 0.34 2.67 0.46 2.82 0.49 2.90 0.50 3.14 0.50 3.29 0.50
25 2.45 0.36 2.61 0.47 2.76 0.51 2.84 0.51 3.08 0.52 3.23 0.53
32 2.31 0.48 2.47 0.57 2.62 0.60 2.70 0.60 2.94 0.62 3.10 0.63
35 2.25 0.54 2.41 0.61 2.57 0.63 2.64 0.62 2.88 0.65 3.04 0.66
40 2.15 0.59 2.31 0.63 2.47 0.64 2.55 0.65 2.78 0.66 2.94 0.67
43 2.09 0.58 2.25 0.60 2.41 0.60 2.49 0.60 2.72 0.61 2.88 0.62
46 2.03 0.52 2.19 0.52 2.35 0.51 2.43 0.51 2.66 0.51 2.82 0.52
12
22 3.34 0.50 3.55 0.67 3.76 0.73 3.87 0.74 4.18 0.74 4.39 0.74
25 3.27 0.53 3.48 0.69 3.68 0.74 3.79 0.75 4.10 0.77 4.31 0.77
32 3.08 0.71 3.29 0.83 3.50 0.88 3.60 0.89 3.92 0.91 4.13 0.92
35 3.00 0.79 3.21 0.90 3.42 0.93 3.52 0.91 3.84 0.96 4.05 0.98
40 2.87 0.87 3.08 0.93 3.29 0.95 3.39 0.95 3.71 0.97 3.92 0.99
43 2.79 0.85 3.00 0.89 3.21 0.89 3.32 0.89 3.63 0.89 3.84 0.91
46 2.71 0.76 2.92 0.77 3.13 0.75 3.24 0.75 3.55 0.75 3.76 0.76
18
22 5.02 0.87 5.33 1.18 5.64 1.28 5.80 1.30 6.27 1.31 6.59 1.31
25 4.90 0.93 5.21 1.22 5.53 1.31 5.68 1.33 6.15 1.35 6.47 1.36
32 4.62 1.25 4.94 1.47 5.25 1.54 5.41 1.56 5.88 1.60 6.19 1.63
35 4.50 1.39 4.82 1.58 5.13 1.64 5.28 1.61 5.76 1.69 6.07 1.72
40 4.31 1.53 4.62 1.65 4.93 1.67 5.09 1.67 5.56 1.70 5.88 1.74
43 4.19 1.50 4.50 1.57 4.82 1.56 4.97 1.56 5.44 1.58 5.76 1.61
46 4.07 1.34 4.38 1.36 4.70 1.33 4.85 1.31 5.32 1.31 5.64 1.35
2 Units Operation
12+12
22 6.69 1.28 7.11 1.72 7.53 1.87 7.74 1.89 8.36 1.91 8.78 1.91
25 6.53 1.35 6.95 1.77 7.37 1.91 7.58 1.94 8.21 1.97 8.62 1.99
32 6.16 1.82 6.58 2.15 7.00 2.25 7.21 2.28 7.84 2.33 8.26 2.37
35 6.01 2.03
6.42 2.30 6.84 2.39 7.03 2.35 7.68 2.46 8.10 2.51
40 5.74 2.23 6.16 2.40 6.58 2.44 6.79 2.44 7.42 2.48 7.83 2.53
43 5.58 2.18 6.00 2.29 6.42 2.28 6.63 2.28 7.26 2.30 7.68 2.35
46 5.43 1.96 5.84 1.98 6.26 1.94 6.47 1.92 7.10 1.92 7.52 1.97
9+18
22 6.69 1.28 7.11 1.72 7.53 1.87 7.74 1.89 8.36 1.91 8.78 1.91
25 6.53 1.35 6.95 1.77 7.37 1.91 7.58 1.94 8.21 1.97 8.62 1.99
32 6.16 1.82 6.58 2.15 7.00 2.25 7.21 2.28 7.84 2.33 8.26 2.37
35 6.01 2.03 6.42 2.30 6.84 2.39 7.03 2.35 7.68 2.46 8.10 2.51
40 5.74 2.23 6.16 2.40 6.58 2.44 6.79 2.44 7.42 2.48 7.83 2.53
43 5.58 2.18 6.00 2.29 6.42 2.28 6.63 2.28 7.26 2.30 7.68 2.35
46 5.43 1.96 5.84 1.98 6.26 1.94 6.47 1.92 7.10 1.92 7.52 1.97
12+18
22 6.69 1.28 7.11 1.72 7.53 1.87 7.74 1.89 8.36 1.91 8.78 1.91
25 6.53 1.35 6.95 1.77 7.37 1.91 7.58 1.94 8.21 1.97 8.62 1.99
32 6.16 1.82 6.58 2.15 7.00 2.25 7.21 2.28 7.84 2.33 8.26 2.37
35 6.01 2.03 6.42 2.30 6.84 2.39 7.03 2.35 7.68 2.46 8.10 2.51
40 5.74 2.23 6.16 2.40 6.58 2.44 6.79 2.44 7.42 2.48 7.83 2.53
43 5.58 2.18 6.00 2.29 6.42 2.28 6.63 2.28 7.26 2.30 7.68 2.35
46 5.43 1.96 5.84 1.98 6.26 1.94 6.47 1.92 7.10 1.92 7.52 1.97
3 Units Operation
9+9+9
22 6.69 1.19 7.11 1.61 7.53 1.75 7.74 1.77 8.36 1.78 8.78 1.79
25 6.53 1.27 6.95 1.66 7.37 1.79 7.58 1.82 8.21 1.85 8.62 1.86
32 6.16 1.70 6.58 2.01 7.00 2.11 7.21 2.13 7.84 2.18 8.26 2.22
35 6.01 1.90 6.42 2.16 6.84 2.24 7.03 2.20 7.68 2.30 8.10 2.35
40 5.74 2.09 6.16 2.25 6.58 2.28 6.79 2.29 7.42 2.32 7.83 2.37
43 5.58 2.04 6.00 2.14 6.42 2.14 6.63 2.13 7.26 2.15 7.68 2.20
46 5.43 1.83 5.84 1.86 6.26 1.81 6.47 1.80 7.10 1.80 7.52 1.84
9+9+12
22 6.69 1.19 7.11 1.61 7.53 1.75 7.74 1.77 8.36 1.78 8.78 1.79
25 6.53 1.27 6.95 1.66 7.37 1.79 7.58 1.82 8.21 1.85 8.62 1.86
32 6.16 1.70 6.58 2.01 7.00 2.11 7.21 2.13 7.84 2.18 8.26 2.22
35 6.01 1.90 6.42 2.16 6.84 2.24 7.03 2.20 7.68 2.30 8.10 2.35
40 5.74 2.09 6.16 2.25 6.58 2.28 6.79 2.29 7.42 2.32 7.83 2.37
43 5.58 2.04 6.00 2.14 6.42 2.14
6.63 2.13 7.26 2.15 7.68 2.20
46 5.43 1.83 5.84 1.86 6.26 1.81 6.47 1.80 7.10 1.80 7.52 1.84
To Next Page
