Certication & Reliability
Safety
Cell UL1642, IEC62619
Battery Pack
CE,RCM,UL1973,IEC62619,
IEC62477-1
EMC FCC,IEC61000-6-1/-2/-3
Hazardous Materials
Classication
Class 9
Transportation UN38.3
Ingress Rating IP55
※ Test Conditions: Temperature 25°C/77°F, at the beginning of life.
※ Energy is measured under specic conditions from LG Energy Solution (0.3CCCV/0.3CC).
1) Value for battery pack only. Maximal usable energy at the AC output may vary by condition, such as
inverter efciency, conguration and temperature.
2) Peak current excludes repeated short duration (less than 10 sec. of current pattern).
2.1.3 Arc Flash Protection Calculations
In order to protect personnel from the possibility of getting injured by an
arc ash Hazard, Arc ash calculation of the battery system is estimated
with the Incident Energy calculations refer to Annex D of NFPA 70E.
Model name
RESU FLEX
8.6
RESU FLEX
12.9
RESU FLEX
17.2
Battery System Voltage 235V 352V 470V
Battery System Internal
Resistance
0.240 Ω 0.349 Ω 0.473 Ω
Bolted Fault Current 1.260kA 1.013kA 0.766kA
Arcing Current 0.630kA 0.506kA 0.383kA
Clearing Time 250us 250us 250us
Arc Flash Incident Energy 0.000168 0.000261 0.000344
Working Distance 450mm(18inches)
Battery system installers must wear PPE (Personal Protective Equipment)
according to NFPA 70E Article 130.
