LG RESU FLEX - Install Battery Pack for Stand Type

ENGLISH
23
3.6.3 Install Battery Pack for Stand type
1. Assemble the Basic standing bracket
Basic
M6 Bolt
M6 bolt (a torque of 5N·m)
Basic standing bracket
When adding Optional Standing Bracket
Bolt 8ea(a torque of 5N·m)
Basic Standing Bracket
Pack Standing Bracket
*Optional Standing Bracket is for additional purchase and is not included in basic package.
