SERIAL COMMUNICATION FUNCTION
17. Picture Mode (Command: ns)
► Sets the picture mode.
Transmission [n][s][][Set ID][][Data][Cr]
Data
00:
Vivid
01:
Standard
03:
Cinema
05:
Game
06:
Black Mode
07:
Expert
1
08:
Expert 2
(* Transmitted in hexadecimal code)
Ack [s][] [Set ID][][OK][Data][x]
Data
00:
Vivid
01:
Standard
03:
Cinema
05:
Game
06:
Black Mode
07:
Expert
1
08:
Expert 2
(* Transmitted in hexadecimal code)
18. Mute (Command: ke)
► Enables/disables the mute function.
Transmission [k][e][][Set ID][][Data][Cr]
Data
00:
Mute On (Volume Off)
01:
Mute Off (Volume On)
Ack [e][] [Set ID][][OK][Data][x]
Data
00:
Mute On (Volume Off)
01:
Mute Off (Volume On)
19. Volume (Command: kf)
► Adjusts the volume.
Transmission [k][f][][Set ID][][Data][Cr]
Data Min: 0
H
to Max: 64
H
(* Transmitted in hexadecimal code)
* See the data structure.
Ack [f][] [Set ID][][OK][Data][x]
Data Min: 0H(Vol 0) to Max: 64H(Vol 100)
20. Monitor Out (Command: nr)
► Select either RGB1 or RGB2 input as an output
of the RGB OUT port.
Transmission [n][r][][Set ID][][Data][Cr]
Data
00: RGB 1 01: RGB 2
02:
Auto
Ack [r][] [Set ID][][OK][Data][x]
Data
00: RGB 1 01: RGB 2
02:
Auto
