13
1 - GENERAL FEATURES
1.8 YARN OUTPUT DETECTION FEELER
The assembly of this detection feeler onto the feeder output, enables the
machine to receive a stop signal that is relayed by the feeder when it detects
output yarn snaps/breaks.
Installation: once the feeler has been fixed onto the feeder using the nuts and
bolts provided on the support bracket, connect up the wire with the three-way
connector located on the feeder housing.
