LGL Electronics EcoPower - Transformer Kit

2.3 TRANSFORMER KIT
20
2 - INSTALLATION AND START-UP
NO
NC
COM
Machine
stop cable
Ground to machine
(Yellow/Green)
Ground to
machine
(Yellow/Green)
Ground from
transformer
(Yellow/Green)
48 VAC from
transformer
Flat Cable
Machine
stop cable
Ground from
transformer
(Yellow/Green)
48 VAC from
transformer
Flat Cable
Up to 10 Feeders
N.B: For installation of machines with large diameters please refer to the
specific instructions attached to the power kit.
