5 - MAINTENANCE OPERATIONS
5.1 REMOVAL OF THE YARN SPOOL BODY
Proceed as follows to remove the yarn spool body:
1) Power down the yarn feeders by actuating the main switch located
on the knitting machine.
2) Disconnect the flat strip power cable and disassemble the feeder. Lift it off
the machine.
3) Unscrew the 3 set screws (11) and remove the guard (2).
11
2
