MT86 Operation and Maintenance Manual
7
Fig.1-15
Fig.1-16
Fig.1-17
Fig.1-18
Fig.1-19
Fig.1-20
7) ―Working safety‖ signs: at front end and in the
middle of the cargo body.
8) Buffer tank operation Caution: beside the buffer
tank.
9) Air reservoir Caution: at the external wall of the
air reservoir.
10) Travelling Caution: at the left upper corner of
front windshield. （LHD）
13) hydro-cylinder notice：at the right front side of
the seat in cab.
