Figure 2-3. Close up of the Odyssey
®
Fc control
module showing the power receptacle and ethernet
connectors (use only the supplied ethernet cable).
All other connectors on this panel should not be
used.
Power Receptacle
Ethernet
connectors
Power Receptacle
Ethernet
connectors
Figure 2-4. Rear panel showing air intake fan.
Keep the intake unblocked during operation
and accessible for routine filter cleaning
(Chapter 3).
Air intake fan
