Liebert 7200 Series - Series UPS USER MANUAL

7200 Series UPS USER MANUAL
document in response to "powersure ups"
Page ii
Issue 6
(03/98)
This manual describes the following equipment:
EQUIPMENT PART NUMBER
30 kVA UPS Module 5410305 R
40 kVA UPS Module 5410307 T
60 kVA UPS Module 5410310 W
Battery Cabinet Type `B' 38 Ah
• with battery circuit breaker (BCB) 100 A
• without BCB and side panels
5320031 P
5320034 S
Battery Cabinet Type `C' 50 Ah
• with battery circuit breaker (BCB) 100 A
• with battery circuit breaker (BCB) 160 A
• without BCB and side panels
5320032 Q
5320037 V
5320035 T
Battery Cabinet Type `D' 85 Ah
• with battery circuit breaker (BCB) 160 A
• with battery circuit breaker (BCB) 250 A
5320038 W
5320039 X
Battery Circuit Breaker Box 100 A (for UPS 30 to 40 kVA) 4641027 B
Battery Circuit Breaker Box 160 A (for UPS 60 kVA) 4641028 C
Battery circuit breaker control board 4520067 T
Temperature sensor board 4532029 V
Input harmonic filter 30 kVA 4641015 P
Input harmonic filter 40 kVA 4641016 Q
Input harmonic filter 60 kVA 4641017 R
AS400 alarm interface board 4590055 P
Additional 3 x AS400 interface board 4590057 R
External alarm interface board 4590056 Q
Remote Alarm Monitor (RAM) 4305001 Z
Remote/Local Communications kits. 4645102 U
Parallel kit 4645004 A
Auxiliary Battery Distribution Box 125A 4641031 F
Auxiliary Battery Distribution Box 250A 4641032 G
