Liebert 7200 Series - Chapter 8 - Specification Single Module; MECHANICAL CHARACTERISTICS; ENVIRONMENTAL; INPUT RATINGS

7200 Series UPS User Manual Chapter 8 - 1+1 Parallel System
Single Module and 1+1 Parallel System Specification Single Module
document in response to "powersure ups"
Page 8-1
Issue 6
(03/98)
8. Chapter 8 - Specification Single Module
MECHANICAL CHARACTERISTICS UNITS Model kVA Rating
30 40 60
Height mm 1400
Width mm 710
Depth mm 800
Weight Kg 480 540 620
Colour (two tone) — RAL 7001
Protection grade — With enclosure - IP 20
With front door open - IP 20
Ventilation — by internal intake fans
Airflow m
3
/h 480 960
Cable entry — Bottom
ENVIRONMENTAL UNITS Model kVA Rating
30 40 60
Operating temperature °C 0- +40
Maximum temperature for 8 hr day — 40°C derate by 1,5% per °C between +40°C + 50°C
Mean temperature for 24 hr day °C 35 max.
Relative humidity —
≤ 90% at 20°C
Altitude
≤1000m asl(derate by 1% per 100m between 1000 and 2000)
Storage temperature °C -25 to +70
Acoustic noise at rated load.
(1 meter from the apparatus according to
ISO3746)
dBA 56
EMC standard — Designed to meet EN 50091-2, class A.
Safety Standard — Designed to meet EN 50091-1.
INPUT RATINGS UNITS Model kVA Rating
30 40 60
Power consumption at rated load while
float charging the battery
kVA 32,8 43,5 64,9
Power consumption at rated load while
boost charging the battery
kVA 41,0 54,3 81,1
Input current level normal running
(Vin 400V)
A 47,0 63,0 94,0
Input current level full battery recharge
(Vin 400V)
A 59,0 78,0 117,0
Line voltage V a.c. 380 - 400 - 415 3 Ph + N
Current rating of neutral cable A 1,4 times rated current
Permissible input voltage variation % +10 –15
Frequency Hz 50 or 60
Permissible input frequency variation %
± 5
Power walk-in — Progressive over 2 seconds
Power factor at 380/400/415V
cos Φ
0,8
With optional input filter fitted
cos Φ
> 0,9
