Chapter 6 - Trouble shooting 7200 Series UPS User Manual
Trouble shooting UPS system Single Module and 1+1 Parallel System
document in response to "powersure ups"
Page 6-2
Issue 6
(03/98)
Fault Reporting
Irrespective of whether fault rectification is successful or not, report the fault occurrence to the nearest
service agent who will then forward the details to the manufacturer. This type of customer feedback is
an important factor in maintaining high product reliability, and also provides important data concerning
the equipment field performance.
Caution
The following diagnostic charts are designed for 'first aid' trouble shooting only. If a problem cannot be resolved
by taking the actions given then fully trained assistance should be sought immediately.
Do not under any circumstances make internal circuit adjustments or interfere with the circuit boards in any other
way.
%
3
1
2
4
5
7
9
6 8
Figure 6-A . Details
