Liebert DM Series User Manual

48 Appendix 3 RDU-Cooling Air-Conditioner Single-Unit Manager Software Introduction
New Liebert_DM Series Air Conditioner User Manual
Click Alarm Sound (ON) to turn on the alarm sound, and Alarm Sound (ON) turns to Alarm Sound (OFF).
Functions of the RDU-Cooling manager include:
 Simple HMI (human-machine interface): The RDU-Cooling manager supports simple HMI function. You can
change the site background picture and drag the site or equipment to change its icon location at will.
 Data query: Current equipment operating data, current alarm data, curve report and history data of the
Liebert_DM AC can be queried.
 Alarm notification: The RDU-Cooling manager can send an e-mail and a short message to the user when an
alarm occurs to the equipment.
 Remote control: The RDU-Cooling manager provides remote control function for the Liebert_DM AC.
 Remote adjustment: The RDU-Cooling manager provides remote adjustment function for the Liebert_DM AC.
 Report management: The RDU-Cooling manager provides alarm report, operating data report, operating data
curve report and system log report of the Liebert_DM AC, and supports multiple pages display of the report and
data export functions.
 User management: Users can be added, modified, deleted, and given different levels of software operation
authorities according to their duties.
As shown in Figure 2, the menu area provides five menus, as described in Table 1.
Table 1 Menu description
Menu
Description
Device Monitoring
This menu allows you to add, change and delete device/site; configure alarm notificaition function; view
current analog signal data, status signal data, and alarm information of the device; perform remote control
and adjustment over the device
Alarm Manage
This menu allows you to query the real-time alarms and configure the alarm notification parameters
Report Manage
This menu allows you to query history alarm, history device data, cuive report and history system logs. It
also provides print and print preview functions
System Manage
This menu includes User Manage and System Title.
User Manage menu allows you to add, delete users, modify user information, and give them different
levels of operation authorities according to their duties;
System Title menu allows you to set the system title of the RDU-Cooling manager
Online Help
The Online Help menu provides an electronic file of the manual. Selecting this menu opens the electronic
file of RDU-Cooling Air-Conditioner Single-Unit Manager User Manual
 Note
1. The RDU-Cooling software CD is included in the unit accessory for free.
2. For detailed descriptions of RDU-Cooling, refer to RDU-Cooling Air-Conditioner Single-Unit Manager User Manual. This
manual is installed together with the software on the computer, and you can find it through the Online Help menu.
