Appendix 2 Parameter Setting Table
Menu
Parameter
Default
Setting range
Alarm
Menu
Alarm Setpoint
Hi Temp
35°C
25°C ~ 50°C
Lo Temp
15°C
5°C ~ 20°C
Hi Hum
65%RH
65%RH ~ 90%RH
Lo Hum
35%RH
10%RH ~ 35%RH
Air loss
25°C
30°C
Alarm output
(general alarm)
ENAB OFF, ENAB, DISA
Alarm output
(serious alarm)
ENAB DISA, ENAB
Customer 1
NC (the unit equipped with
SPD is NC by default)
NO, NC
Customer 2
(remote shutdown)
NC NO, NC
Set Points
TempStpt
24°C
15°C ~ 35°C
TempSens
3°C
1°C ~ 5°C
Hum Stpt
50%RH
20%RH ~ 80%RH
Hum Sens
5%RH
1%RH ~ 10%RH
System
Status
Analog
Temp Calib
0.0°C
-10°C ~ +10°C
Hum Calib
0.0%
-10% ~ +10%
NTC0 Calib
0.0°C
-10°C ~ +10°C
In/Out Status
Manual Run Enab
NO
YES, NO
In Fan Output
OFF
ON, OFF
Comp Output
OFF
ON, OFF
Heat Output
OFF
ON, OFF
Hum Output
OFF
ON, OFF
Low air Output
OFF
ON, OFF
Out Fan Output
OFF
ON, OFF
System
Menu
Setup System
Mntr Addr
1
1 ~ 254
Mntr Prtcl
YDN23
YDN23, MODBUS
Baut Rate
19200
1200 ~ 19200
Over Press
15%
10% ~ 30%
Under Press
15%
10% ~ 30%
Pwr Freq Devia
3Hz
2Hz ~ 5Hz
In Fan Start
10s
10s ~ 600s
In Fan Stop
30s
10s ~ 300s
Comp Run
180s
60s ~ 300s
Comp Stop
180s
60s ~ 300s
Cold St Delay
180s
30s ~ 240s
Hum Control
RH
RH, AH
Temp Compsen
OFF
ON, OFF
Factory Reset
NO
YES, NO
Fan type
AC
AC, EC
EC max. output
74%
50% ~ 100%
EC dehum output
60%
40% ~ 90%
Outdoor Unit
Min. Volt
30%
30% ~ 50%
Max. Volt
100%
60% ~ 100%
Press BdWdth
5Bar
4Bar ~ 6Bar
Start Press
13Bar
11Bar ~ 15Bar
Select Options
Heat
0
0, 1
Hum 0
0, 1 (set Heat Num to 1 before setting
Hum Num to 1)
Select
Options_CostSave
Mod_Economy Mod
Economy Mod
OFF
OFF, ON
Start At
22:00
18:00 ~ 3:00
End At
7:00
5:00 ~ 10:00
Zoom
2°C
2°C ~ 10°C
