Lighthouse S3100/S5100/Boulder Counter Operating Manual
2-4 248083389-1 Rev
SOLAIR
Specifications
3100 Size Ranges 0.3 - 25.0μm
Channel Thresholds Standard and Optional, 6 & 8 Channels:
0.3, 0.5, 0.7, 1.0, 2.0, 3.0, 5.0, 7.0, 10.0,
25.0μm
5100 Size Ranges 0.5 - 25.0μm
Channel Thresholds Standard and optional, 6 and 8 channels:
0.5, 0.7, 1.0, 2.0, 3.0, 5.0, 7.0, 10.0, 25.0μm
Boulder Counter Size
Range
5.0 - 100.0m
Channel Thresholds 5.0, 10.0, 25.0, 40.0, 50.0, 100.0 μm
Flow Rate 1.0 CFM (28.3 LPM)
Counting Efficiency 3100: 50% @ 0.3 m; 100% for particles >
0.45 m (per ISO 21501-4)
5100: 50% @ 0.5 m; 100% for particles >
0.75 m (per ISO 21501-4)
Laser Source Extreme Life Laser diode
Zero Count Level <1 count/5 minutes (per ISO 21501-4)
Concentration Limits 500,000 Particles/ft
3
@ 5% Coincidence Loss
Calibration NIST Traceable
Count Modes Concentration, manual, automatic, beep
Data Storage Stores up to 3000 sample records of particle &
environmental data, plus location and time
Communication Modes Ethernet TCP/IP, RS485/Modbus, RS232 via
RJ-45 to PC, USB, USB Flash Drive
Supporting Software LMS XChange Data Transfer Software
Optional: LMS Express/RT, LMSNet
External Connections PIC connector; USB-B and Flash Drive USB-
A; Ethernet RJ45, RS485 RJ45, Calibration
port, 4-20 Analog ports, AC IN.
Analog Inputs Up to four optional 4-20mA analog sensors
Touch Screen Display 5.7" (14.47 cm), 320x240 pixels
Printer Thermal printer, optional, specify at time of
order
Table 2-1 Solair Specifications
