Operating Counter
248083389-1 Rev 6-21
Zoomed Analog Data Display
When the instrument is Holding or is not Counting, the user can touch
anywhere on the Particle Data display area to activate the Zoomed Data
View. Touch the Particle button to switch view to analog data. See
Figure 6-27.
Figure 6-27 Zoomed Analog Data Displayed
SAMPLE
The SAMPLE screen allows the user to configure the number of cycles,
count times and volumes when running a sample. See Figure 6-28.
Figure 6-28 Sample Timing Configuration Screen
Particle Button
Particle Data
display area
