4-2 and Fig. 4-3). Please note
the fuel tray (item 10) which is
lo cated be low the car bu re tor to
pre vent fuel from drip ping onto
hot en gine com po nents.
Po si tion of the notch in gas ket
(1) is also very im por tant to en -
sure the func tion of the car bu re -
tor. Check the air fil ter flange
of the car bu re tor and make sure
that the open ings are not cov
-
ered with the gas ket.
Flugmotoren
4
Prepared by: J. B. Meyer Replaces edition from: 10.03.86 Page: 4-3
Checked by: Edition: 01.03.1999 Reg. Number:
Installation Manual
L 1700, L2000 and L 2400 Series
Fig. 4-3 Sample Carburetor Preheat System L 2000 EB1AA (Twin
Carburetor) Series
