Cal i bra tion of RPM-indicator (250.215.001.000)
Ad just the “0” point first. Then run up en gine to ap prox i -
mately 2500 - 3000 rpm, mea sure the pro pel ler rpm with
a cal i brated op ti cal ta chom e ter and ad just the “R” screw
ac cord ingly.
5.3.3.2 Connection of RPM indicatorwith 9-Pin
connector
RPM in di ca tor (250.215.001.000)
Pin Des ti na tion
1 +12 V
2 +12 V
3 Input Sensor+
6 Input Sensor-, GND
5
Prepared by: J. B. Meyer Replaces edition from: 10.03.86 Page: 5-6
Checked by: Edition: 01.03.1999 Reg. Number:
Installation Manual
L 1700, L2000 and L 2400 Series
0
5
10
15
20
25
30
35
40
x100
Fig.5-3 RPM indicator 250.215.001.000
O
R
Fig. 5-4 RPM indicator
250.215.001.000.000 rear view
1
2
3
4
5
6
7
8
9
Fig. 5-5 Pin Assignments 9-Pin
Connector
To Next Page
