5 ELECTRICAL SYSTEM
5.1 Description
The power out put of the starter largely de pends on both the size of the bat tery and the
cross-section of the ca ble. The starter will draw a cur rent of up to 300A.
Cau tion: Be aware of a pos si ble fire haz ard when in stall ing the starter ca ble.
5.2 L 2000 Series Engines
The L 2000 se ries en gines have a 12V elec tri cal sys tem for both the starter and the al ter na tor,
a 24 V Sys tem is avail able on re quest. Ob serve the wir ing di a gram.
Rec om mended fig ures for the bat tery ca pac ity are 12V/28Ah and a cross-section for the starter
ca ble 16mm².
Ac cord ing to your in stal la tion, these fig ures may vary con sid er ably.
5
Prepared by: J. B. Meyer Replaces edition from: 10.03.86 Page: 5-1
Checked by: Edition: 01.03.1999 Reg. Number:
Installation Manual
L 1700, L2000 and L 2400 Series
