Sign De scrip tion Po si tion Part No.
M1 Starter motor attached to the engine
P1 Indicator lamp cockpit 170.215.120.000
P2 Indicator, oil
temperature
cockpit 170.215.100.000
P3 Indicator, oil pressure cockpit 170.215.110.000
P4 Indicator, fuel quantity cockpit selection of the designer
P5 Indicator, engine speed only if electr. tacho.
spec.
201.215.001.000
P6 Indicator CHT cockpit 170.215.001.000
S1 Switch, main cockpit selection of the designer
S2 Button, starter cockpit selection of the designer
S3 Switch, fuel pump cockpit selection of the designer
S4 Switch, ignition cockpit selection of the designer
S5 Switch, 4 position CHT cockpit 170.215.015.000
T1 Magneto attached to the engine
Y1 Fuel pump, electric 170.090.010.000
Z1 Condenser attached to the engine
Z2 (optional) Filter, radio suppression Bosch 0 290 801 001
5.4.2 L 2400 EF Engine
BILL OF MA TE RIALS FOR THE WIRING DI A GRAM
Sign De scrip tion Po si tion Part-No.
B1, B2 Sender, RPM attached to the engine
B3 Sender, throttle position attached to the engine
B4 Sender, air pressure mounted behind
firewall
B5 Sender, air temperature attached to the engine
B6 Sender, water
temperature
attached to the engine
B7 Sender, oil temperature attached to the engine
B8 Sender, oil pressure attached to the engine
B9 Sender, fuel pressure attached to firewall 250.127.220.000
F1 Main circuit breaker
(50A)
cockpit ETA 2-5700-K12-55A
