The LP3 is developed for vertical lifts and can resist a bending moment by virtue of the
effective telescopic system.
The lifting column is designed for applications where a small installation dimension is
requested without compromising the lifting capacity.
The LP3 is characterised by having a lower installation dimension proportional to the
stroke length compared to the LP2. The LP3 can also attain a higher speed than the
LP2.
The telescopic column is compatible with LINAK’s control boxes and can run individually; as 2 x LP3 parallel and/or with memory.
The LP3 is the perfect choice for height adjustment on dental, gynaecologist, and wheelchairs as well as for operating, office and working benches etc.
The column can only be loaded with the maximum bending moment over the first 80 % of the stroke. The maximum bending moment will
be reduced to 50 %.
The column must be mounted with the largest profile uppermost!
• There are mounting holes in the end plates.
• The largest profile must be mounted uppermost.
Warning
Do only use the column within specified working limits.
Warning
Ensure a safe connection between column and application
Warning
Side mounting bracket screws: use the correct torque on the side mounting bracket screws.
Warning
The column can not be used in pull
Warning
Max. bending: LP3 = 375 Nm
6. LP3 (MEDLINE
®
CARELINE
®
TECHLINE
®
)
