Page 177 of 192
SIM card
Specifications and requirements:
• SIM card type to be used: Mini SIM also called 2FF (it is possible to use SIM adapter for other SIM types which are not delivered by LINAK).
• The SIM card must support voice communication and minimum 2 MB monthly data.
• The CCM needs to know the SIM card provider’s Access Point Name (APN).
Most providers’ APN is known; if, however, the provider is unknown, the APN will be added to the data base.
• The CCM must be unpowered when inserting/removing the SIM card!
• Before inserting the SIM card into the CCM, the PIN code must be deactivated, allowing the CCM to contact the server. Afterwards, the PIN code
can be reactivated in the CCW to protect the exchangeable SIM card against misuse.
Handling:
The SIM card is to be inserted on the back of the CCM by opening the SIM card lid,
See the illustration below.
Maximum screw torque = 0.35 [Nm]
Be aware to insert the SIM card with the chip downwards. Ensure that the SIM card lid is screwed on carefully,
maintaining the spacing washers on each screw.
Recommendations:
• The CCM is only intended for indoor use.
• The CCM is only working when connected to mains. There is no battery back-up.
See the usage section for mains indicator.
• To ensure the IP degree, always use locking rings and cables with O-rings.
• The CCM must be cleaned at regular intervals to remove dust and dirt and to ensure that neither loudspeaker nor microphone is blocked.
• During cleaning, cables must remain plugged in, correctly fitted with O-rings, and the SIM card lid must be closed to prevent water ingress.
• The CCM is resistant to the majority of cleaners and disinfectants used in the care sector. However, the detergents must comply with the following
basic requirements:
- no high alkaline or acid content (pH value 6-8)
- no caustic content
• Do not spray disinfectants directly on to the microphone or speaker, but use a cloth for disinfection.
• The CCM is a handsfree communication device for fixed mounting and not intended for portable operation.
• We recommend to test the system before use to be sure that the selected SIM card works as expected..
Warnings
Be aware that the CCS is not intended as a life-supporting or emergency equipment. It is only intended as a communication and comfort system for
people in need of care.
