3.3 Connect local smoke detectors (up to 4)
Connect local smoke detectors to master unit.
Maximum 4 smoke detectors could be connected directly to the master unit (FDS-M).
FDS-M
L N
FDS-M
G0 D01 G0 D02 G0 D03 G0 D04
Fire damper 1
12
Fire damper 2
FDS-M
+C S2_1
Fire damper 1
S4 S2
S6_1
S1 S6
+C S2_2
S4 S2
S6_2
S1 S6
Fire damper 2
+C S2_3 S6_3 +C S2_4 S6_4
12
Power supply
0 230V 0 24V BA
G G0
Slave unit
AB
Master unit
3.1
3.2
3.3
3.4
+
FDS-M
Smoke detector
L1outL1in L2
2,2 kΩ
Ceiling smoke detector
FDS-M
Smoke detector
53 4
2,2 k
Ω
Duct smoke detector
12
-+-+-+-
+-+-+-+-
G
FDS-M
L N
FDS-M
G0 D01 G0 D02 G0 D03 G0 D04
Fire damper 1
12
Fire damper 2
FDS-M
+C S2_1
Fire damper 1
S4 S2
S6_1
S1 S6
+C S2_2
S4 S2
S6_2
S1 S6
Fire damper 2
+C S2_3 S6_3 +C S2_4 S6_4
12
Power supply
0 230V 0 24V BA
G G0
Slave unit
AB
Master unit
3.1
3.2
3.3
3.4
+
FDS-M
Smoke detector
L1outL1in L2
2,2 k
Ω
Ceiling smoke detector
FDS-M
Smoke detector
53 4
2,2 kΩ
Duct smoke detector
12
-+-+-+-
+-+-+-+-
G
3
The FDS-M switchboard have four 2.2 kΩ resistors
on each smoke detector connection.
Remove the resistor if you add a smoke detector and
move the resistor to smoke detector.
The resistor is still required, see image 2 and 3.
2
+ - + - + - + -
1 2 3 4
1-2
SMOKE DETECTORS
1-2 1-2 1-2
FDS-CD FDS-DD
