Servicing 5
Inspection and maintenance as required
e3861375
1
2
¾ Insert a screwdriver in opening (1) and lift
fastener (2) to open.
¾ Open side battery door (6), move to right
andlockwithcatch(7).
NOTE
Battery doors which can be moved through
180° (special equipment) are released to-
gether via cable pull. Release is effected by
the lever also used to open the battery cover.
Operating Instructions – 386 807 1001 EN – 03/2006 95
