Linde E14 - Type sheet E 16, (battery 48 V; 4 PzS; 440 L) Edition 09;2005

Technical data 6
Type sheet E 16, (battery 48 V / 4PzS / 440L) Edition 09/2005
Type sheet E 16, (battery 48 V / 4PzS / 440L) Edition 09/2005
1 Identification
1.1
Manufacturer (abbreviation)
Linde
1.2
Type designation of manufacturer
E16
1.3
Drive electric, diesel, petrol, gas, mains electric
Electric
1.4
Operation manual, go, stand, sit, commissioner
Sit
1.5
Capacity / Load Q [kg]
1600
1.6
Centre of gravity c[mm]
500
1.8 Load distance
x[mm]
365
1.9 Wheel base
y[mm]
1301
2 Weight
2.1
Own weight (without mast)
kg
3055
2.2
Axis load with load front / rear
kg
4091 / 564
2.3
Axis load without load front / rear
kg
1427 / 1628
3 Wheels, tyres
3.1
Tyres solid rubber, SE, air, polyurethane
SE
3.2
Tyre size, front
18 x 7 - 8
3.3
Tyre size, rear
15 x 4 1/2 - 8
3.5
Wheels, number front / rear (x = driven)
2x/2
3.6 Front tread
b10 [mm]
930
3.7 Rear tread
b11 [mm]
168
4 Tilt lift mast/fork carriage, forward/reverse
4.1
Tilt lift mast / fork carriage, forward / reverse α/β (°)
5.0 / 7.5
4.2
Height lift mast retracted h1 [mm]
2044
4.3 Free stroke
h2 [mm]
150
4.4
Lift
h3 [mm]
2840
4.5
Height lift mast extended h4 [mm]
3441
4.7
Height above protective roof (cab) h6 [mm]
1970
4.8
Sitting height / standing height h7 [mm]
908
4.12
Coupling height h10 [mm]
510
Operating Instructions – 386 807 1001 EN – 03/2006 155
