Circuit diagrams 7
Wiring diagram basic equipment page 3
A2 Combi-control
3B2 Steering column sensor
K1 Contactor coil main contactor
1S1 Seat switch
1S2 Hand brake switch
1S3 Footbrake switch
2B6 Temperature sensor axle
X4 Connection contactor coil K1, 2-pole
X13 Connector plug A2, 121-pole
1X4 Connector plug 1S2, 2-pole
1X6 Connector plug 1S3, 2-pole
1X9 Connector plug 1S1, 2-pole
3X2 Connector plug 3B2, 4-pole
9X15 Connector plug special equipment, 18-pole
2Y1 Valve lower
2Y2 Valve lift
2Y3 Valve tilt forwards
2Y4 Valve tilt backwards
2Y5 Valve addition 1B
2Y6 Valve addition 1A
2Y7 Valve addition 2B
2Y8 Valve addition 2A
2Y9 Safety valve
2Y10 Accumulator charging valve
Wire colours
BK Black
BN Brown
BU Blue
GN Green
GY
Grey
OG
Orange
RE Red
VT
Purple
WH White
YE Yellow
The number before the wire colour refers to
the wire cross-section.
Wires without specification of cross-sec-
tion = 0.75 mm
2
b shown activated
1
The switch is activated when the footbrake is
in the neutral position.
2
The switch is activated when the handbrake
is not applied.
Operating Instructions – 386 807 1001 EN – 03/2006 207
