Overview 3
Indicator unit
(5)Indicator light error control system or
battery charger operation (colour red)
Lights up with malfunctions in the electrical
control system or with battery charger oper-
ation. An error code is displayed in text field
(25) at the same time.
(6)Indicator light direction
of travel forwards
(colour green)
Lights up when forwards motion is selected
using the direction selector switch with single-
pedal vehicles .
(7)Indicator light load / overload indicator
(colour yellow/red) (special equipment)
Lights up yellow with normal loa
d.
DANGER
Symbol lights up red with overloading.
Set down load immediately.
Consult load diagram.
(8)Indicator light crawler mode activated
(colour green)
Lights up when selector switch for crawler
mode is operated.
(9)Indicator light direction of travel backwards
(colour green)
Lights up when reverse motion is selected
using the direction selector switch with single-
pedal vehicles .
(10)Indicator light consult operating manual
(colour yellow)
Lights up with a possible operating error and
shows an error code in text field (25).
(11)Battery discharge indicator (LED bar
display)
Shows the current charge state of the battery.
The 7 green LEDs are extinguished one af-
ter the other as the battery increasingly dis-
charges. Once the battery is 80% discharged,
the red LED with the battery symbol lights up.
As the battery discharges further (battery ca-
pacity < 20%), the red LED flashes.
(12)Symbol lift height indicator (special
equipment)
If this function is activated, the lift height is
shown in the first line of the text display (25)
. The lift height indicator can be set to either
metres or feet.
(13)Symbol steering position
indicator (spe-
cial equipment)
The second line of the text display( 25) shows
the steering angle . If the steering angle
indicator is switched on, the symbol (13) lights
up on the indicator unit.
(14)Symbol service interval exceeded
When the key switch is switched o
n, display
(22) shows the operating hours u
ntil the next
service for approx. 5 sec. At the
same time
symbol (23) lights up.
Adjustment and reset of the intervals is only
possible with the diagnostic software provided
for this purpose.
Please contact your authorised dealer.
(15) Symbol hour meter active
The operating hours of the vehicle are shown
in display (22) . The hour meter symbol (15)
flashes and the operating hours are counted
with the vehicle switched on and the seat
switch activated.
(16) Symbol clock (am/pm), speed display
(km/h/mph)
(17) Function key
Assignment depending on version
(18) Reset button (special equipment)
To adjust the time, switch off the a
udio warning
signal and other functions depend
ing on the
version.
(19)Display clock
24-hour clock display
Can be adjusted using keys (17) and (1
8.)
Resetting to 12-hour clock display is possible
via diagnostic device.
Please contact your authorised dealer.
Operating Instructions 386 807 1001 EN 03/2006 21
