System Outputs
e eMerge Essential provides up to 4 door lock relays and 4 auxiliary output relays that may be
activated in response to reader activity, time schedules or input conditions. All relays are Form-C
SPDT and provide non-powered dry contacts rated for 1A.
Output Defaults
All outputs are assigned default features that can be congured as needed. e following table
shows the default states for each of the outputs:
Table 5.2: Default Output States
Output Default State Default Response
Door Lock Outputs 1-4 Not Energized, Single Pulse
3 second unlock time in response to corresponding reader
activity (Reader 1 activates door 1 lock relay)
Aux Outputs 1-4 Not Energized, Single Pulse No default response. Must be configured via programming.
Wiring Requirements
e cable must be the proper gauge for the current load and should not be bundled with other
wiring. Refer to the Table 5.3 for wiring recommendations:
Table 5.3: Recommended Wiring Requirements
Total Amps Voltage (AC or DC)
Wiring Gauges and Distance
14 16 18 20 22
.5 A
12V 1500 ft 1000 ft 600 ft 375 ft 225 ft
24V 2000 ft 1200 ft 750 ft 450 ft 300 ft
1.00 A
12V 800 ft 500 ft 300 ft 200 ft 100 ft
24V 1000 ft 600 ft 400 ft 200 ft 150 ft
2.00 A
12V 400 ft 240 ft 150 ft 90 ft 60 ft
24V 480 ft 300 ft 180 ft 120 ft 70 ft
3.00 A
12V 260 ft 160 ft 100 ft 60 ft
24V 320 ft 200 ft 120 ft
