D9U003VB3-0101_0424/65
4.7 Cover(allcongurations)
Top
4 way stretch with 360 degree zip
waterproof / high Moisture Vapour Permeability / Dartex
Base
high durability / non stretch / waterproof / PU coated nylon material
2 strong mattress Transport Handles on each side of the base
6 strong Mattress Fixing Straps with „mini Trident style“ quick release clips
mattress rolling strap for ease of transport/storage
4.8 BaseCover(allcongurations)
4.8.1 Transport Handles
Transport Handles are intended for transport of the mattress.
WARNING!
Materialdamageandriskofinjuryduetoincorrectuse!
Transport the mattress using Transport Handles without patient on it!
Fig. Base cover description
1 7
2
3 4 5
6
1. Transport Handle
2.
3. Head Zone Selector (Virtuoso With Head & Heel Zoner and Virtuoso Pro)
4. Body Zone Selector (Virtuoso Pro only)
5. Heel Zone Selector (Virtuoso With Head & Heel Zoner and Virtuoso Pro)
6. Strap for mattress transport
7. Cable routing clip
HEAD
